Description
• Light weight and easily transportable
• Flexible design, can suit any ambulance.
• Expandability (integrated with ventilator, compressor and other monitors)
• Easily sliding infant bed.
• User friendly control panel offers strain viewing.
• Electrically operated suction module.
• Separate infant temperature probe.
• Acrylic infant hood with parts for infant access and portals for other tubings.
• IV pole.
• Examination lamp.
• Houses a 3 ltr O2 cylinder.
• Reduced noise and vibration inside infant crib.
| Temperature Module
Probe………………….Thermistor probe Heater element……Encapsulated heater with fins. Probe Calibration……Not Required Range………………….25° C to 40° C Accuracy…………….. ± 0.2° C Accuracy of probe inter changeability…………. ± 0.2° C Resolution………….. 0.1° C Voltage………………….220 V to 240V at 50/60Hz Battery backup………………….3 hrs. |
HEATER:
Single element CE approved ceramic heater placed in a parabolic reflector.Heater output control range in manual mode: 0 to 100% |
| Operating environment
Operating temperature …………-10 to +60° CStorage temperature……………..-25 to 60° COperating humidity……………….0 to 95% RH |
|
| Oxygen Supply
Incorporates a 3 ltr water capacity oxygen cylinder with pin index.Auxillary cylinder 10 ltrs water capacity (optional) |
Infant bed dimension
Length…………….. 700mm Width………………. 300mm Height……………… 35mm |
| Electrical Suction (Optional)
Maximun Suction…………….. 400mm HgVacuum gauge range………. 0-760mm Hg |
Alarms
Power down alarms (more than 10 min.)System failure.Heater failure.Power failure (Optional)Battery low (Optional) Probe failure |
| Canopy dimension
Length…………….. 800mm Width………………. 430mm Height……………… 400mm |
Coating
Epoxy powder coated body for scratch protection and rust prevention. Polyurethane painted baby bed and air path for easy cleanability.Conform to IEC 601 safety standard for medical equipment. |
| Control unit dimension
Length…………….. 850mm Width………………. 450mm Height………………160mm |
Trolley Dimension
Height………………..1000mm Width…………………500mm Length……………….650mm |
