Description
| Canopy | 900x450x430mm |
| Mattress | 525x380mm |
| Height | 1425mm |
| Depth | 585mm |
| Width | 945mm |
| Baby Tray | Fixed tray with Mattress |
| Castors | 125mm diameter, with brakes |
| Warm-up time to 37°C | 20 min @ 20 °C |
| Ambient temperature control | 28 °C to 39 °C, 0.5 °C incrmt. |
| Skin temperature | 35 °C to 38 °C, 0.5 °C incrmt. |
| Noise level inside Canopy | <45 dBA. |
| Air velocity over bed | <25 cm/sec. |
| Air filter capacity | 99% (for 0.5um) |
| Air and skin temp. sensor accuracy | +/- 0.1 °C |
Salient Features:
The Electrical Controller:
- The Controller based on Micro computerized systems.
- Large bright display for easy monitor and for viewing from a distance.
- Digital display system provided to measure the Infant temperature, Air Temperature and to set the required temperature.
- Feather touch keys provided for easy for easy operation.
- Bar graph LED system to indicate the heater output.
Fault Indications with Alarm for-
- For skin and air temperature too low or high, fan failure, heater failure, power failure, skin and air probe failure, canopy open,
temperature >39°C in any mode, control module open and circuit fault.
Baby Probe / Air Probe:
- Baby probe / Air probe is made of highly sensitive sensor and interchangeable, field calibrations taken care of by software. The probe is made up of silicon sheathed cable, which allows easy cleaning.
Other Facilities:
- IV Stand Provided
- Front panel with large door and 2 port holes.
- Rear: 2 port holes and 4 holes for tubes
- Combined window rotation and closing system
- Stand with integrated base cabinet.
- Three Storage drawers
- Transfer handle
- Guard rail and support
- Fitted with support for O2 cylinder
- Platform for use with monitor or pulse oximeter (Optional)
